OEM Sinotruk Brake Light Switch 811W25503-0001 | ASIL-B Certified with 1 Million Cycle Rating

OEM Sinotruk Brake Light Switch 811W25503-0001 | ASIL-B Certified with 1 Million Cycle Rating

‌Technical Specifications‌:

• OEM Part Number: 811W25503-0001
• Application: All SITRAK models with EBS
• Contact Type: Self-cleaning silver alloy
• Electrical Rating: 24V DC, 10A resistive
• Activation Force: 5-7N
• Travel: 3.2±0.2mm
• Operating Temp: -40°C to +125°C
• Protection: IP67 (submersible)
• Safety Level: ISO 26262 ASIL-B
• Mechanical Life: 1,000,000 cycles
• Connector: AMP Superseal 1.5 series
• Compliance: ECE R13-H, FMVSS 108

‌Installation Notes‌:

1. ‌Safety First‌:

   • Disconnect battery and depress brake pedal 10x to discharge residual pressure

2. ‌Removal‌:

   • Unclip wiring harness (press orange lock tab)
   • Rotate switch 45° counterclockwise

3. ‌Installation‌:

   • Pre-set plunger to 3.2mm protrusion
   • Verify 0.5mm free play before engagement
   • Torque to 8Nm ±5%

4. ‌Testing‌:

   • Check brake lights activate within 1.5mm travel
   • Verify no false triggering during vibration

5. ‌Critical Notes‌:

   • Must use scan tool to clear EBS error codes
   • Never lubricate contacts
